Description

The most common crystalline form of calcium carbonate. Calcite is widely distributed throughout the world as chalk, limestone, and marble. Major deposits were formed from ancient sea beds and hard water deposits (e.g., stalactites). Iceland is famous for producing large clear birefractive calcite crystals that are used in optical systems (Iceland spar). In addition to clear colorless crystals, calcite may also appear white or pale shades of other colors depending on the crystal size and the presence of impurities. Marble is limestone that has been metamorphosed to form compact crystals of calcite. Calcite has been gathered or mined since Paleolithic times. In the form of chalk, calcite was powdered for use as a pigment and as an ingredient in the manufacture of steel, cement, and glass. Limestone and marble are used for sculpture and buildings.

Calcite

Synonyms and Related Terms

calcium carbonate; marble; limestone; Iceland spar; dogtooth spar; dog-tooth spar; nailhead spar; satin spar; calcareous spar; calc spar; calcspar; calcite (It., Fr., Port.); Kalzit, Calcit (Deut.); calcita (Esp.); calciet (Ned.); calcium salt of carbonic acid; Pigment White 18; CI 7720

Raman


Raman


FTIR

MFA- Calcite (Egyptian limestone).jpg

XRD



Other Properties

Rhombohedral crystal system. Perfect cleavage in three directions. Fracture = conchoidal. High birefringence. Can doubly refract light. Aged surfaces of calcite may fluoresces purple or blue in ultraviolet light; freshly cleaved surfaces are white to yellow. Reacts with acids to evolve carbon dioxide. Luster = vitreous. Streak = white.

Composition CaCO3
CAS 471-34-1
Mohs Hardness 3.0
Density 2.71-2.72
Molecular Weight mol. wt. = 100.09
Refractive Index 1.486; 1.658; (1.566)

Hazards and Safety

International Chemical Safety Card

Additional Information

° R. Gettens, E. West Fitzhugh, R.Feller, "Calcium Carbonate Whites", Artists Pigments, Vol. 2., A. Roy ed. Oxford University Press, Oxford, 1993.

° Mineralogy Database: Calcite

Comparisons

Properties of Common Abrasives


Additional Images


Sources Checked for Data in Record

  • Thomas Gregory, The Condensed Chemical Dictionary, Reinhold Publishing, New York, 3rd ed., 1942 Comment: Mohs =2
  • Van Nostrand's Scientific Encyclopedia, Douglas M. Considine (ed.), Van Nostrand Reinhold, New York, 1976 Comment: Mohs=3
  • R. J. Gettens, G.L. Stout, Painting Materials, A Short Encyclopaedia, Dover Publications, New York, 1966
  • G.S.Brady, Materials Handbook, McGraw-Hill Book Co., New York, 1971 Comment: p. 138, Mohs=3
  • C.W.Chesterman, K.E.Lowe, Audubon Society Field Guide to North American Rocks and Minerals, Alfred A. Knopf, New York, 1979
  • Jack Odgen, Jewellery of the Ancient World, Rizzoli International Publications Inc., New York City, 1982
  • A.Lucas, J.R.Harris, Ancient Egyptian Materials and Industries, Edward Arnold Publishers Ltd., London, 4th edition, 1962
